1300mm Hot Melt PUR Laminating Machine 61.2KW 1000-2600mm 30m/min
| Place of Origin: | CHINA |
| Brand Name: | Sheng jin |
| Model Number: | RTM1300 |
| Minimum Order Quantity: | 1 SET |
| Price: | USD56888~59999/SET |
| Packaging Details: | 1×40 HC+1×20GP |
| Delivery Time: | 20 Working Days |
| Payment Terms: | T/T ,Deposit 30% Remaining 70% before departure |
| Supply Ability: | 2 SET /Month |
|
Detail Information |
|||
| Place of Origin | CHINA | Brand Name | Sheng jin |
|---|---|---|---|
| Model Number | RTM1300 | Visual Size: | 12334×3600×2800mm |
| Motor Power: | 12.54KW | Total Power: | 61.2KW |
| Automatic Grade: | Semi-Automatic,Customizable Automatic | Voltage: | 380V/50HZ |
| Whole Line Control: | Equipment For The Whole Line Control | High Light: | Hot Melt PUR Laminating Machine,1300mm PUR Laminating Machine,hot melt coater laminator 30m/min |
Product Description
RTM1300 PUR Hot Melt Glue Laminating Machine
1. Usage:
Laminating MLB(Multi laminating board)/PVC foam board /MDF/CHIP board with surface decorative sheet or coil.
2. Two Coating Models Of Face Materials:
(1) Basic Board:MLB(Multi laminating board)/PVC foam board /MDF/CHIP Board
(2) Face Materials
① Sheet model:Acrylic/HPL
② Film continue model:PVC/PET film
3. More Descriptions:
Keywords:PUR Glue//Hot-melt Glue/Pasting,Laminating,Coating Machine/ PVC/ PET/ Acrylic
(1) Main Material:Steel welding/Aluminum/A3 Steel plate/Rubber roller/steel roller/Cylinder
(2) Machine Color:Customizable
(3) Driven type:Electric
(4) Condition:New
(5) Warranty:1Year
(6) After-sales service provided:Engineers available to service machinery overseas,Video technical support,Online support
(7) Voltage:380V/50HZ (Or other industrial demand voltage, but the delivery time needs to be increased by 10 working days)
| Effective length of sheet | 1000- -2600mm |
| Maximal width of sheet | 1300mm |
| Effective thickness of coating plate | 2- -50mm |
| Effective thickness of composite sheet | 5-70mm |
| Motor power | 12.2KW |
| Production speed | 30m/min |
