63KW PUR Laminating Line Coating Laminating Machine PVC PET Film
Product Details
| Place of Origin: | CHINA |
| Brand Name: | Sheng jin |
| Model Number: | RTM1300A PUR Sticking Machine |
Payment & Shipping Terms
| Minimum Order Quantity: | 1 SET |
| Price: | USD55500~66000/SET |
| Packaging Details: | Pearl cotton + winding film packaging（1×40 HC +1×20 GP） |
| Delivery Time: | 20 work days |
| Payment Terms: | T/T ,Deposit 30% Remaining payment 70% before departure |
| Supply Ability: | 3 SET /Month |
|
Detail Information |
|||
| Place of Origin | CHINA | Brand Name | Sheng jin |
|---|---|---|---|
| Model Number | RTM1300A PUR Sticking Machine | Laminate Material: | PVC,Acrylic,PET,PETG,HPL |
| Feature: | Customizable | Glue: | PUR Hot-melt Adhesive |
| Total Power: | 63KW | Warranty: | 12Months |
| High Light: | 63KW pur laminating line,pur laminating line PVC PET Film,Coating Laminating Machine HPL |
||
Product Description
PVC PET Film Coating Laminating Machine Using PUR Glue
Time limit for delivery:After received deposit 20 working days
Technical parameters
1. Plate effective Max width: 1300mm；
2. Plate effective length:400-2600mm；
3. Glued Plate effective thickness:2—50mm
4. Composite Plate effective thickness:5—70mm
5. Speed:5-20m/min
6. Working height:800mm
7. Weihgt:7400KG (1×40 HC +1×20 GP 8 Packages)
8. Visual size13400×3600×2800mm
Two laminate models
1.Sheet model:
MLB(Multi laminating board)/PVC foam board /MgO board /
MDF/CHIP Board laminate Acrylic/HPL/PET sheet.
2.Film continue mode:
MLB(Multi laminating board)/PVC foam board /MgO board /
MDF/CHIP Board laminate PVC/PET film.
