PVC HPL Acrylic Electric Automatic Lamination Machine 800-1300mm 63KW
Product Details
| Place of Origin: | CHINA |
| Brand Name: | Sheng jin |
| Model Number: | RTM1300A |
Payment & Shipping Terms
| Minimum Order Quantity: | 1 SET |
| Price: | USD61800~66000/SET |
| Packaging Details: | 1×40 HC+1×20GP （Pearl cotton + winding film packaging） |
| Delivery Time: | 25 Working Days |
| Payment Terms: | T/T |
| Supply Ability: | 2 SET /Month |
|
Detail Information |
|||
| Place of Origin | CHINA | Brand Name | Sheng jin |
|---|---|---|---|
| Model Number | RTM1300A | Usage: | Laminating MLB(Multi Laminating Board)/PVC Foam Board /MDF/CHIP Board With Surface Decorative Sheet Or Coil. |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support | Weight: | About 7300KG |
| Driven Type: | Electric | Warranty: | 18 Months |
| Visual Size: | 13400*3600*2800mm(With Crane) | High Light: | HPL Acrylic Automatic Lamination Machine,PVC Automatic Lamination Machine,auto lamination machine 63KW |
Product Description
PVC HPL Acrylic Automatic Lamination Machine
1. Basic Panel:
MLB(Multi laminating board)/PVC foam board /MDF/CHIP Board
2. Two Laminating Models Of Face Materials:
① Sheet Model:Like Acrylic/HPLthickness0.35-2mm)
② Film Continue Model:LikePVC/PET film thickness 0.1mm-0.5mm but High gloss PVC film thickness more than 0.4mm
3. More Details:
Deposit 30% Remaining payment 70% before departure
4. Technical parameters
① Boardeffective width:800-1300mm
② Board effective length:2000-2500mm
③ Glued Board effective thickness:5—50mm
④ Composite Board effective thickness:5—70mm
⑤ Speed:5-20m/min
⑥ Opreating height:800mm
⑦ Total power: About 63KW
