5-20m/min Double Gluing Hot Melt Adhesive Coating Machine 1600-2500mm
| Place of Origin: | CHINA |
| Brand Name: | Sheng jin |
| Model Number: | RTM1300 Doubl Gluing |
| Minimum Order Quantity: | 1 SET |
| Price: | USD106000~122000/SET |
| Packaging Details: | 2×40 GP |
| Delivery Time: | 30-40 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2 SETS /Month |
|
Detail Information |
|||
| Place of Origin | CHINA | Brand Name | Sheng jin |
|---|---|---|---|
| Model Number | RTM1300 Doubl Gluing | Usage: | Woodworking，Construction，Furniture |
| Type: | Hot Melt Glue | Application: | Panel Honeycomb Board Bonding |
| Other Names: | Hot Melt Adhesive Sticking Machine | Keywords: | Honeycomb /Hot Melt Adhesive /PUR Laminate |
| High Light: | Hot Melt Adhesive Coating Machine,hot melt coating machine 1600mm,hot melt coating machine 2500mm |
||
Product Description
RTM1300 Doubl Gluing Hot Melt Adhesive Coating Machine
Capability and use:
The machine is specially developed for customers,it’s a new special-purpose equipment.It consists of seven standalone unit and a PUR glue supply.The unit for the manufacturer required to laminate various substrate.Including wood design on face of three layer sandwich composite panels,and cellular core plate, other board etc.
Technical parameters:
1. Board max effective width:1000-1300mm
2. Board effective length:1600-2500mm
3. Board effective thickness:2-50mm
4. Effective thickness of composite Door:5-70mm
5. Equipment operating height:800mm
6. Motor power:19.34kw
7. Speed:5-20m/min
8. Total power:about 70kw
9. Visual size:21300×3600×2200mm(L×W×H)
10. The equipment is equipped with a dustproof system and a monitoring system.
11. Control mode: the equipment is the whole line control
